Online PH Meter

Get a Price/Quote

MOQ : 1 Unit

Online PH Meter Specification

Temperature Range
0C to 60C

Connectivity Type
4-20 mA Output

Current Range
4-20 mA Output

Humidity %
0-95% RH (Non-condensing)

Diameter
Refer probe type

Protection
IP65 Enclosure

Application Media
Water, Industrial solutions

Flow Rate
Suitable for inline flow (refer to probe specs)

Measurement Range
0.00 to 14.00 pH

Sensor Type
Glass Electrode

Resolution
0.01 pH

Capacity
Continuous Monitoring

Pressure Range
0 to 6 bar

Frequency
50/60 Hz

Equipment Type
Online PH Meter

Material
ABS Plastic

Power Supply
230 V AC, 50 Hz

Power Consumption
Less than 5 VA

Accuracy
0.01 pH

Display Type
Digital LED Display

Range
0 to 14 pH

Calibration
Automatic / Manual

Compliance
CE Marked

Cable Length
Standard 5 m (customizable)

Electrode Material
Glass with Reference Solution

Operating Voltage
230 V AC

Controller Mounting Type
Panel / Wall Mounting

Output Signal
Relay Contact for Alarm

Enclosure Material
ABS / Polycarbonate

Display Size
3 Digit, 7-Segment

Alarm
Built-in High/Low Alarm

About Online PH Meter

Our Top-rated Online PH Meter is Highly Recommended for water and industrial applications, earning its place as a Featured, Sought-after solution across India. Decorated for reliability, this sublime meter offers Panel/Wall Mounting and delivers rapid pH readings ranging from 0.00 to 14.00 with 0.01 accuracy. Its Digital LED Display is protected in an IP65 ABS/Polycarbonate enclosure, and the glass electrode ensures precise measurement. Automatic or manual calibration, built-in high/low alarms, and 4-20 mA connectivity empower seamless, continuous monitoring-making it the preferred choice for dealers, manufacturers, suppliers, and wholesalers.

Remarkable Features and Application Surfaces of Online PH Meter

The Online PH Meter's Special Features include automatic/manual calibration, built-in high/low alarms, and a robust IP65-protected enclosure. With its digital LED display and 0.01 pH resolution, accurate readings are assured in real time. Designed for versatility, this device suits water and various industrial solutions, providing reliable surface application whether installed in-line or panel/wall mounted. Its glass electrode and ABS/polycarbonate body deliver consistent measurement performance, making it invaluable in demanding environments.

Supply Ability, Certifications & Express Shipping for Online PH Meter

Our supply chain ensures continuous availability of this Online PH Meter, backed by CE certification for quality assurance. With express shipping and efficient logistics, shipped goods are promptly dispatched from India's major FOB ports. The packaging and delivery process is streamlined, enabling clients to receive their orders on time-every time. As a decorated supplier, we guarantee swift, reliable supply to dealers, wholesalers, and manufacturers, making this meter a sublime addition to your analytical equipment portfolio.

FAQ's of Online PH Meter:

Q: How do I calibrate the Online PH Meter for accurate measurements?

A: The Online PH Meter offers both automatic and manual calibration options. You can follow the user manual instructions to perform calibration based on your specific measurement needs. Automatic mode simplifies the process, while manual calibration allows precision adjustment for more demanding applications.

Q: What benefits does the built-in high/low alarm on the PH Meter provide?

A: The built-in alarm system instantly notifies you when pH readings exceed set thresholds, promoting operational safety and facilitating timely intervention to maintain process stability and product quality.

Q: When should I use the panel versus wall mounting option?

A: Use panel mounting for installations within cabinet systems or control panels, and select wall mounting for open or vertical surfaces near tanks or pipelines, based on your site's layout and monitoring requirements.

Q: Where can the Online PH Meter be applied most effectively?

A: This meter is ideal for water treatment facilities and a variety of industrial solutions-including manufacturing, chemical processing, and laboratory environments-thanks to its robust construction and wide pH range.

Q: What is the process for connecting the PH Meter to my monitoring system?

A: Connect the PH Meter to your monitoring or SCADA system using the standard 4-20 mA output provided. The unit comes with a 5-meter cable (customizable) to facilitate flexible installation and integration with existing infrastructure.
