Online Conductivity Meter

Get a Price/Quote

MOQ : 1 Unit

Online Conductivity Meter Specification

Current Range
0-20 mA / 4-20 mA output

Connectivity Type
Terminals for Signal Output

Temperature Range
0C to 50C

Measurement Range
Up to 2000 S/cm

Frequency
50 Hz

Pressure Range
Ambient

Protection
IP65 (Front Panel)

Sensor Type
Conductivity Cell (Dip Type)

Equipment Type
Online Conductivity Meter

Application Media
Water, Process Liquids

Capacity
Standard industrial applications

Resolution
0.1 / 1 S/cm

Diameter
Suitable for standard panel mounting (approx. 96 x 96 mm)

Humidity %
90% RH (Non-condensing)

Material
ABS Plastic Enclosure

Power Supply
230V AC, 50 Hz

Power Consumption
<5 VA

Accuracy
1% of F.S.

Display Type
Large Digital LED Display

Range
0 - 199.9 S/cm / 0 - 1999 S/cm

Mounting Type
Panel Mount

Electrode Material
Platinum/Graphite (as per order)

Compensation
Automatic Temperature Compensation (optional)

Calibration
Manual, front panel accessible

Output Signal
Isolated 0-20 mA / 4-20 mA Analog

Weight
Approx. 600 grams

Alarm Relay
Configurable SPDT relay output

Cable Length
Standard 2 meter sensor cable

Display Color
Bright Red LED

About Online Conductivity Meter

Experience precision with our Online Conductivity Meter, crafted for those who demand stellar performance and reliability. Designed for panel mounting, this radiant instrument offers both 0-20 mA and 4-20 mA isolated analog outputs and features a configurable SPDT relay for alarm functions. Manual calibration is effortlessly accessible on the front panel, while optional automatic temperature compensation ensures accuracy under varying conditions. With a bright red LED display, platinum/graphite electrodes, and robust ABS enclosure (IP65 protected), this top-tier device is available in limited stock-an ephemeral opportunity for those seeking scarce, quality instruments in industrial environments across India.

How to Use: Features and Application Method

Simply mount the Online Conductivity Meter on a standard 96 x 96 mm panel and connect it using the provided terminals. Calibration is manual and conveniently front-accessible, allowing real-time adjustments. The instrument outputs isolated analog signals, with optional automatic temperature compensation for consistent accuracy. Suitable for various process liquids, it excels in industrial water quality and process monitoring. Configure relay alarms as needed, ensuring a stellar measurement experience under ambient pressures and temperatures.

Packaging, Sample Availability, and Quick Delivery

Each Online Conductivity Meter is securely packaged to prevent damage during transit, supporting rapid, hassle-free installation. Stock is ready for immediate dispatch, ensuring prompt delivery at the lowest price. Interested dealers, manufacturers, or wholesalers can request product samples. We prioritize swift logistics and efficient customer service, aiming to get this scarce, high-demand equipment to you as quickly as possible, wherever you are located within India.

FAQ's of Online Conductivity Meter:

Q: How does the Online Conductivity Meter ensure measurement accuracy?

A: The meter achieves 1% accuracy of full scale through manual front panel calibration and optional automatic temperature compensation, ensuring reliable results in varying process conditions.

Q: What is the process for installing and connecting the device?

A: Install the meter into a standard 96 x 96 mm panel mount, connect the terminals for signal output, and use the supplied 2-meter sensor cable. The user-friendly design guarantees a straightforward installation process.

Q: Where can this meter be used?

A: It is ideal for industrial applications involving water and various process liquids, making it suitable for manufacturers, dealers, suppliers, and wholesalers across India seeking high-performance process monitoring.

Q: What are the benefits of the configurable SPDT relay alarm?

A: The configurable SPDT relay allows users to set threshold alarms, enabling instant alerts when conductivity exceeds predefined limits, thereby safeguarding your processes and equipment.

Q: When is automatic temperature compensation advisable?

A: Automatic temperature compensation is highly recommended when there are frequent fluctuations in process temperature, as it ensures the meter delivers precise readings regardless of environmental changes.
